Taru XL Waterproof LED Linear Fixture

Note: When installing, leave .25" of free space on each side of the channel to allow for the natural expansion of the unit when in use.

Taru XL LED Linear fixtures are a new and revolutionary type of fixtures that provides an even and crisp light. Taru LED Fixtures are water resistant IP55 and can be used Indoors and Outdoors.

Taru XL LED fixtures are manufactured by infusing a thick 3 sided diffuser to the fixtures body done through injection molding systems. This create a 3 sided viewing angle with clean, even, and crisp lines of lights. Thanks to the fusion between body and the diffusing material, you can expect the same look as Square neon.

Taru XL LED Fixtures offer an unsurpassed style and elegance, while providing accent lighting to any hi end project.

Taru XL Fixtures are manufactured to order and are available in any size between 6 and 78 inches. Taru fixtures are fully dimmable and are available in a multitude of color temperatures and colors.

Mounting Brackets are included with each order. Longer units get more brackets in order to hold the unit effectively.

Main Features:

Manufactured to Order up to 78 inches:
We can manufacture any length from 6 inches to 78 inches. This enables interior designers and customers to correctly create the perfect ambiance. Other manufacturers only offer linear LED lighting systems in a very short list of sizes. Orders can take anywhere from 7 Days to 15 days to manufacture depending on current production times.

Complete Dotless Solution:
We provide fixtures that are dotless and don’t show LED dots achieved by using proprietary diffusing materials. Other manufacturers use cheap electronics that don’t perform as well. Fully Dimmable: All of our Linear Lighting Systems are fully dimmable.

Fully Customizable:
Units can be customized with different lengths and color temperatures.

Mounting Types:
We offer 2 mounting types: Brackets or Magnetic Mounting. Magnetic Mounting is great for any surface that is made of ferrous metals, like retail shelves and displays. Normal Brackets are great when fixing to non metal surfaces.

How to choose your required drivers:

Solid Apollo’s linear fixtures require a driver to work (not included). It’s easy to know what driver you will need with the following instructions:

1. Count how many total inches of fixtures you have in the same line. For example: If you purchase two fixtures of 60 inches each for one line, you will have a total of 120 inches.
2. Choose which type of driver you wish to have in your setup from the selection below. Use the length of your line from step one to determine which driver to select. For example: If we wanted a plug and play driver for the 120 inch line from step one, we’d pick option three from the first section, From 97 to 192 Inches: LED Power Supply 24V-DC-4A-96W.

Normal 24V DC Drivers with Plug and Play connectors:

1. From 0 to 48 inches of total length: LED Power Supply 24V-DC-1A-24W
2. From 49 to 96 inches of total length: LED Power Supply 24V-DC-2A-48W
3. From 97 to 192 inches of total length: LED Power Supply 24V-DC-4A-96W

24V DC Drivers with Hardwire installation:

1. From 0 to 120 inches of total length: Hard Wired LED Power Supply 24V-DC-60W
2. From 121 to 200 inches of total length: Hard Wired LED Power Supply 24V-DC-100W

Dimmable 24V DC Drivers:

1. From 0 to 100 inches of total length: Dimmable LED Transformer 50W 24V DC
2. From 101 to 190 inches of total length: Dimmable LED Transformer 96W 24V DC

If your installation requires larger drivers, give us a call and we will be happy to recommend the right product that fits your needs.

In a Nutshell:

• 0.87in (W) x 0.71in (H)
• Available from 6 to 78 Inch lengths (1 inch increments)
• Up to 596 lm/ft
• Indoor/Outdoor use
• 3 Sided Diffuser
• Ultra Clean and Even Lighting
• Neon Like Effect. Subtle and Clean
• Made to Order
• Fully Dimmable
• 5 Year Warranty
• Available in 2400K, 2700K, 3000K,
  3500K, 4000K, 5000K, and 6000K
• Manufactured in the USA

* Please note: This is a product that is made to order. These units are non returnable because of this. Production time usually is 7 days, but could be more depending on current production times.
